Sirio WY400-10N Basisantenne

Art.nr. 4021
Niet op voorraad
Excl. BTW € 135,00 € 111,57
11.85 dBd – 14 dBi, 10 elements Yagi,400-470 MHz (KAN NIET WORDEN VERZONDEN, ALLEEN OPGEHAALD)

Description

-Base station antenna, Directional

-Wide band, High-gain

-Highly symmetrical radiation pattern in both planes (E and H)

-Protection from static discharges DC-ground

-Made of anodized aluminium alloy

-Stacked and bayed array for more gain

-Optional: tilting bracket for +-20°

Electrical Data


  • Type 10 element Yagi
  • Frequency range 400 - 470 MHz
  • Impedance 50 ? Unbalanced
  • Polarization Linear Vertical or Horizontal
  • Radiation (H-plane) beamwidth at -3 dB= 50° at 435 MHz
  • Radiation (E-plane) beamwidth at -3 dB= 45° at 435 MHz
  • Max Gain 14 dBi
  • Front to Back ratio = 18 dB
  • S.W.R. in bandwidth = 1.5:1
  • Max Power 150 Watts (CW) at 30°C
  • Feed system / Position RG303 PTFE coax with balun / inside boom
  • Lightning protection DC-ground
  • Connector N-female with rubber protection cap


Mechanical Data

  • Materials Anodized 6063-T5 Aluminium,
  • Thermoplastic UV stabilized, Chromed Brass
  • Wind load / resistance 150 N at 150 Km/h / 120 Km/h
  • Wind surface 0.120 m2
  • Dimensions (approx.) 2000 x 375 mm
  • Weigth (approx.) 2040 gr
  • Turning radius 1860 mm
  • Operating temperature -40° C to +60° C
  • Mounting Mast Ø 35-52 mm
Meer Lezen
Meer informatie
Vrachttype L
Vergunning Nee
Merk Sirio
