Sirio Gainmaster 5/8 golf SI 2113220.00

Art.nr. 8233
Op voorraad
Excl. BTW € 189,00 € 156,20
Antenna CB Base, for CB & 10 mtr, Fiber White, 736cm, 500W.(ALLEEN AF TE HALEN)

Description

Afwijkende afmeting voor verzending,

FEATURES, FUNCTIONS AND SPECIFICATIONS:

ELECTRICAL DATA


  • - Type: 0.625 ? center feeded vertical dipole
  • - Frequency Range: @ SWR ? 2.0 25.5 - 30 MHz 400 CB channel 10m ham band
  • - Impedance: 50 ?
  • - Radiation: Omnidirectional
  • - Polarization: Linear Vertical
  • - Max Gain on the horizon: 1 to 2 dB higher than conventional 5-8 ?
  • - Max Power: 500 Watts (CW) continuous, 1000 Watts (CW) short time
  • - Ligthning protection: All metal parts are DC-grounded, the inner conductor shows a DC-short
  • - Connector: UHF-female, PTFE insulator gold plated central pin


MECHANICAL DATA:

  • - Materials: Whip made of white fiberglass four sections composite tube, radiator made of copper wire and low loss coax cable, stainless steel hardware, anodized AW6060 aluminium, UV stabilized thermoplastic.
  • - Wind Resistance: up to 160 Km-h
  • - Height: (approx.) 7360mm with bracket, radiator 6850mm
  • - Mounting mast: Ø 35-54 mm side mast with “V” bolt PACKING INCLUDES: Antenna User manual in Italian and English Mounting Material
Meer Lezen
Meer informatie
Vrachttype L
Vergunning Nee
Merk Sirio
