Manson SPA-8250 Power Supply 13,8V DC / 25 A

This series of high current, fixed voltage, regulated switching mode power supplies are built with, Over Voltage Protection for safe-guarding voltage sensitive load. High efficiency cuts the running cost and active Power Factor Correction (PFC) maximizes the main's available power.

They are suitable for applications in telecommunications such as radio equipments, RF amplifiers, and other high current applications like car audio, halogen, xenon spot light demonstrations.

The high grade Screw On output terminals are on the back panel of the console while the power on off switch and the bi-colour LED indicator (Power On /Overload) is at the front. The variable speed thermostatic control cooling fan ensures quiet operation of the power supply in medium load condition.

The small size console fits well with the footprints of most modern telecom equipments.

• High RFI stability
• Over voltage protection at 16.5V
• Current fold-back circuit with LED indicator
• Short circuit protection
• Over temperature cut off protection
• High efficiency >78%
• Power factor correction >0.95
• Variable speed Thermostatic controlled fan quiet operation
• Light weight and small size
• Floating ground design
