Manson KPS-6202 Power Supply 1-36V DC / 0-10 A

Output Voltage 1-36V

Output Current  0-10A

These are cost effective remote programming power supplies with lab graded performance. They are ideal for laboratory , university , work shop , production , quality control and advanced DIY. Computer interface via USB or LAN for cyclical operation. Waveform generator for output voltage. Support SCPI industrial standard.

• Remote Programmable via USB or LAN(with optional LAN Card)
• On housing 10 Steps Waveform generator with cycle periods running
• 3 users defined V & I panel presets for frequent use
• Standard Commands of Programmable Instruments (SCPI) command syntax
• Analogue Remote Control of V, I & output On-Off without computer
• Rotary encoder knob with definitive action of fine and coarse tuning
• Smart cooling fan speed control from zero to full speed
• Self diagnostic check on LED display and cooling fan on start up
• Isolated ground , Active PFC & high power efficiency
• Universal AC input
• Over load , Tracking Over Voltage Protections
• Constant Current limit setting with output open circuit
